BYD EL-PRO 1.6T Three-Wheel Electric Forklift

The BYD EL-PRO 1.6T Three-Wheel Electric Forklift is available with a nominal rated capacity of 1,600 kg and a choice of 3 battery configurations. The EL-PRO series configuration shown here uses battery capacities of 210, 280, 340 Ah, each paired with a specified 100 A charger. This page brings those choices together so buyers can compare the electrical configurations while keeping the same rated capacity and product series.

This three-wheel model is a distinct entry in the range and should be considered separately from the standard truck of the same tonnage. For operations involving repeated turns, rack access and positioning near production equipment, review the actual turning radius and aisle requirements against your floor plan. Include the width of your pallets and the space needed to approach each load when discussing the final truck specification.

Battery selection should reflect how the forklift will be used during a normal shift. A receiving operation with occasional pallet movements has a different duty pattern from a production line with frequent travel and lifting. Record approximate operating hours, travel distances, lifting frequency and available charging breaks. The listed 100 A charger current is a configuration detail; charging duration and supply requirements need to be checked with the matched battery and charger specification.

Potential applications to discuss include replenishing warehouse racks, moving palletized materials between production stations and transferring finished goods to dispatch areas. Share the handling route, door openings, rack clearances and floor conditions so the proposed configuration can be reviewed for the complete operation.

When requesting a quotation, include the required lift height, fork dimensions, preferred battery option and delivery destination. If the forklift must work with a specific attachment or enter a container, describe those requirements at the same time. The final proposal should confirm the mast configuration, dimensional drawing, battery voltage, operating clearances and applicable capacity chart. These details help connect the listed product configuration with your actual handling needs and provide a clear basis for comparing quotations.

Configuration Highlights

• 1.6-ton nominal rated capacity: a configuration to consider for palletized loads within the truck’s approved capacity and load-center limits.
• Three-wheel configuration: clearly distinguishes this truck from the separately listed 1.6T configuration. Verify its actual turning radius and required aisle width against your site layout.
• EL-PRO series: the series designation provided for all three battery options on this page.
• Three battery choices: 210 Ah, 280 Ah or 340 Ah, allowing the battery specification to be discussed alongside your daily workload.
• 100 A charger: the charger-current specification listed for each of the three configurations.

Technical Specifications

The rated capacity is not a guarantee of lifting 1,600 kg at every lift height or with every attachment. Actual permitted loads depend on the final truck configuration and its capacity plate, including the load center, mast and any fitted attachment.

Battery and Charger Options

Ampere-hours describe battery charge capacity; they do not, on their own, specify stored energy or operating time. Battery voltage is needed to calculate nominal energy, and actual working time also depends on load weight, travel distance, lifting frequency, gradients and operating conditions. Likewise, a 100 A charger rating alone does not establish a full-charge time. Request the matched battery and charger specification for the selected configuration.

Applications to Discuss

Potential applications include moving pallets between receiving and storage areas, supplying materials to production lines, transferring finished goods to dispatch areas and carrying out routine stock-handling work. Suitability should be assessed against your actual loads and workplace rather than selected by rated capacity alone.

• Warehouse handling: provide pallet dimensions, aisle widths and the highest storage position to check truck and mast suitability.
• Production support: describe load weights, handling frequency and the route between workstations.
• Receiving and dispatch: specify any dock equipment, trailer access, ramps or overhead restrictions involved.
• Mixed working schedules: share shift length and available charging breaks when comparing battery options.

How to Specify Your Truck

Start with the heaviest load you need to handle, including its pallet or container. Provide the load dimensions and load center, the required lift height and the lowest overhead clearance along the travel route. If the truck must enter a container or pass through a low doorway, include those clearance measurements.

Next, describe your operating surface, gradients, turning space and daily work pattern. Identify any required fork dimensions or attachments. These details allow the proposed configuration to be checked before an order is finalized. Mast height, free lift, overall dimensions, turning radius, travel speed, battery voltage, tire specification and attachment availability are not specified in the supplied configuration list and should be confirmed in the quotation.

Frequently Asked Questions

Which battery options are listed for the 1.6T three-wheel model?

The supplied list includes 210 Ah, 280 Ah and 340 Ah batteries for the EL-PRO 1.6T three-wheel configuration. Each is paired with a listed 100 A charger.

Does a larger battery increase the lifting capacity?

No increase in rated lifting capacity is specified for these battery options. All three configurations are listed as 1.6T. Always follow the capacity plate for the actual truck.

Can the charging time or hours per charge be confirmed from this table?

No. The table does not include enough information to establish either figure. Please request battery voltage, matched charger details and an assessment based on your intended duty cycle.

What information should I send with an inquiry?

Send your preferred battery capacity, maximum load weight, pallet dimensions, required lift height, aisle width, shift schedule, working environment and delivery destination. Include any fork or attachment requirements so they can be addressed in the quotation.

Request a Configuration and Quotation

Contact BYDLIFTER to discuss the BYD EL-PRO 1.6T three-wheel electric forklift and compare the 210 Ah, 280 Ah and 340 Ah options. Email [email protected] or call +86 18020732964 with your operating requirements.
